Fisheye lens HD CCTV IR corrected 1/1.7″ Φ5.6 M12 lens 185° 12MP F2.0 security surveillance
CCL1170185MP Fisheye lens HD CCTV IR corrected 1/1.7″ Φ5.6 M12 lens 185° 12MP F2.0 security surveillance
| IMAGE FORMAT | Φ5.6, 1/1.7″ |
| FOCAL LENGTH | 1.85mm |
| F.O.V.(1/1.7″) | 185°(D) |
| 185°(H) | |
| 185°(V) | |
| RESOLUTION | 12Megapixel |
| OPTICAL DISTORTION | <-97% |
| APERTURE | F2.0 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 34.49mm |
| M. B.F.L. | 5.7mm |
| IR | Corrected |
CCL1170185MP Fisheye lens HD CCTV IR corrected Φ5.6 M12 lens 185° 12MP F2.0 security surveillance
