Fisheye HD lens 1/1.8″ Φ5 190° M12 mount lens F2.0 IR corrected for 6MP 360 panoramic
CCL118016MP Fisheye HD lens 1/1.8″ Φ5 190° M12 mount lens F2.0 IR corrected for 6MP 360 panoramic surveillance
| IMAGE FORMAT | Φ5.0mm 1/1.8″ |
| FOCAL LENGTH | 1.6mm |
| F.O.V. | 190°(D) |
| 190°(H) | |
| 190°(V) | |
| RESOLUTION | 6Megapixel |
| OPTICAL DISTORTION | <-113% |
| APERTURE | F2.0 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 17.1mm |
| M. B.F.L. | 3.01mm |
| IR | Corrected |
CCL118016MP Fisheye HD lens Φ5 190° M12 mount lens F2.0 IR corrected for 6MP 360 panoramic
