CCL118019MP
Fisheye CCTV HD lens IR corrected 1/1.8″ Φ5.4 M12 lens 190° 3MP F2.3 security surveillance
CCL118019MP Fisheye CCTV HD lens IR corrected 1/1.8″ Φ5.4 M12 lens 190° 3MP F2.3 security surveillance
| IMAGE FORMAT | Φ5.4, 1/1.8″ |
| FOCAL LENGTH | 1.9mm |
| F.O.V.@Φ5.4 | 190° |
| F.O.V.@Φ4.22 | 132° |
| RESOLUTION | 3 Megapixel |
| DISTORTION | -105% |
| APERTURE | F2.3 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 24.49mm |
| IR | Corrected |
CCL118019MP Fisheye CCTV HD lens IR corrected Φ5.4 M12 lens 190° 3MP F2.3 security surveillance
