Fisheye CCTV HD lens IR corrected 1/2.3″ Φ4.5 M12 lens 185° 9MP F2.2 security surveillance
CCL123019MP Fisheye CCTV HD lens IR corrected 1/2.3″ Φ4.5 M12 lens 185° 9MP F2.2 security surveillance
| IMAGE FORMAT | Φ4.5, 1/2.3″ |
| FOCAL LENGTH | 1.9mm |
| F.O.V. | 185°(D) |
| 185°(H) | |
| 185°(V) | |
| RESOLUTION | 9MP |
| F-THETA DISTORTION | <-23% |
| APERTURE | F2.2 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 35.2mm |
| B.F.L. | 5.60mm |
| CONSTRUCTION | 9G |
| IR | Corrected |
CCL123019MP Fisheye CCTV HD lens IR corrected Φ4.5 M12 lens 185° 9MP F2.2 security surveillance
