CCL1230428MPF
CCL1230428MPF
Wide Angle M12 S-mount 4mm board lens for IMX117 with HFOV 93° HD 12 megapixel
CCL1230428MPF Wide Angle M12 S-mount 4mm board lens for IMX117 with HFOV 93° HD 12 megapixel.
| IMAGE FORMAT | 1/2.3″ |
| FOCAL LENGTH | 4mm |
| F.O.V. | 118°(D) |
| 93°(H) | |
| 69° (V) | |
| RESOLUTION | 12 MP |
| APERTURE | F2.8 |
| DISTORTION | <-35% |
| MOUNT | M12 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 7.47mm |
| IR | 6G+IR cut filter |
CCL1230428MPF Wide Angle M12 S-mount 4mm board lens for IMX117 with HFOV 93° HD 12 megapixel
