CCL123075MP
CCL123075MP
Low distortion 7.5mm 1/2.3″ 45° M12 mount lens HD 5MP rectilinear scanning
CCL123075MP Low distortion 7.5mm 1/2.3″ 45° M12 mount lens HD 5MP rectilinear scanning
| IMAGE FORMAT | 1/2.3″ |
| FOCAL LENGTH | 7.5mm |
| F.O.V. | 55°(D) |
| 45°(H) | |
| 35°(V) | |
| RESOLUTION | 5 MP |
| DISTORTION | <-1% |
| APERTURE | F2.4 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| B.F.L. | 1.6mm |
| TTL | 11.1 |
| CONSTRUCTION | 2G2P |
CCL123075MP Low distortion 7.5mm 45° M12 mount lens HD 5MP rectilinear scanning
