HD CCTV M12 S-mount 6mm board lens IR corrected 5MP for MI5100 F2.0 surveillance
CCL125060MPR2 HD CCTV M12 S-mount 6mm board lens IR corrected 5MP for MI5100 F2.0 surveillance
| IMAGE FORMAT | 1/2.5″ |
| FOCAL LENGTH | 6mm |
| F.O.V. | 67°(D) |
| 54°(H) | |
| 40°(V) | |
| RESOLUTION | 5 MP |
| DISTORTION | <-24% |
| APERTURE | F2.0 |
| MOUNT(mm) | M12x0.5 |
| IRIS | Fixed |
| B.F.L. | 7.3mm |
| T.T.L. | 23.50mm |
| CONSTRUCTION | 6G |
