CCL127028MPR
CCL127028MPR
HD CCTV wide angle M12 S-mount board lens 2.8mm with IR corrected for OV2710
CCL127028MPR HD CCTV wide angle M12 S-mount board lens 2.8mm with IR corrected for OV2710
| IMAGE FORMAT | 1/2.7″ |
| FOCAL LENGTH | 2.8mm |
| F.O.V. | 140°(D) |
| 112°(H) | |
| 84°(V) | |
| RESOLUTION | 3 Megapixel |
| APERTURE | F2.5 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 5.73mm |
| T.T.L. | 20.9 |
| M.O.D. | 0.2m |
| CONSTRUCTION | 5G |
| IR | Corrected |
CCL127028MPR HD CCTV wide angle M12 S-mount board lens 2.8mm with IR corrected for OV2710
