Low distortion 5mm wide angle M6.5 board lens 1/2.7″ HD 2MP rectilinear scanning short TTL
CCL12705MPF Low distortion 5mm wide angle M6.5 board lens 1/2.7″ HD 2MP rectilinear scanning short TTL
| IMAGE FORMAT | 1/2.7″ |
| FOCAL LENGTH | 5mm |
| F.O.V. | 60° |
| RESOLUTION | 2 MP |
| DISTORTION | <-1% |
| APERTURE | F2.2 |
| MOUNT | M6.5×0.25 |
| IRIS | Fixed |
| M.O.D. | 0.3m |
| T.T.L. | 5.6mm |
| LENS COMPOMEMT | 5P+IR cut |
CCL12705MPF Low distortion 5mm wide angle M6.5 board lens HD 2MP rectilinear scanning short TTL
