CCL128025624MP
CCL128025624MP M12 S-mount wide angle board lens for IMX290
| IMAGE FORMAT | 1/2.8″ |
| FOCAL LENGTH | 2.56mm |
| F.O.V.(sensor IMX290) | 165°(D) |
| 140°(H) | |
| 76°(V) | |
| F.O.V.(1/3″) | 150°(D) |
| 113°(H) | |
| 82°(V) | |
| RESOLUTION | 4 Megapixel |
| OPTICAL DISTORTION | <-72% |
| TV DISTORTION | <-9%(H) |
| APERTURE | F2.4 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| T.T.L. | 14.5mm |
| B.F.L. | 4.38mm |
| CONSTRUCTION | 6G |
CCL128025624MP M12 S-mount wide angle board lens for IMX290
