CCL13080MPR M12 S-mount 8mm HD CCTV board lens with IR corrected.
| IMAGE FORMAT | 1/3″ |
| FOCAL LENGTH | 8mm |
| F.O.V. | 43°(D) |
| 34°(H) | |
| 26° (V) | |
| RESOLUTION | 12 MP |
| APERTURE | F1.8 |
| DISTORTION | -9% |
| MOUNT | M12 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 10.02mm |
| T.T.L.(mm) | 39.9 |
| CONSTRUCTION | 7G |
CCL13080MPR M12 S-mount 8mm HD CCTV board lens with IR corrected
