Low distortion CCTV 12mm M12 S-mount board lens 1/3″ HD IR corrected F1.6 surveillance
CCL1312MP Low distortion CCTV 12mm M12 S-mount board lens 1/3″ HD IR corrected F1.6 surveillance
| IMAGE FORMAT | 1/3″ |
| FOCAL LENGTH | 12mm |
| F.O.V. | 29°(D) |
| 23°(H) | |
| 17°(V) | |
| RESOLUTION | Megapixel |
| DISTORTION | <-2.4% |
| APERTURE | F1.6 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| T.T.L. | 20.95mm |
| LENS COMPOMEMT | 5G |
CCL1312MP Low distortion CCTV 12mm M12 S-mount board lens HD IR corrected F1.6 surveillance
