CCL132010MPFR
CCL132010MPFR
Fisheye HD lens waterproof M12 mount lens 1/3.2″ Φ2.9 205° F2.2 for 4MP OV4689 360 AR panoramic camera
CCL132010MPFR Fisheye HD lens waterproof M12 mount lens 1/3.2″ Φ2.9 205° F2.2 for 4MP OV4689 360 AR panoramic camera
| IMAGE FORMAT | Φ2.9, 1/3.2″ |
| FOCAL LENGTH | 1.0mm |
| F.O.V.(sensor OV4689) | 205°(D) |
| 205°(H) | |
| 205°(V) | |
| RESOLUTION | 4 Megapixel |
| OPTICAL DISTORTION | <-117% |
| APERTURE | F2.2 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 12.00mm |
| M. B.F.L. | 1.23mm |
| COMPONENT | 6G+IR cut |
CCL132010MPFR Fisheye HD lens waterproof M12 mount lens Φ2.9 205° F2.2 for 4MP OV4689 360 AR panoramic camera
