CCL132044MPF
CCL132044MPF
Low distortion wide angle 4.4mm 1/3.2″ 52° M8 mount lens for IMX179 HD 8MP rectilinear scanning
CCL132044MPF Low distortion wide angle 4.4mm 1/3.2″ 52° M8 mount lens for IMX179 HD 8MP rectilinear scanning
| IMAGE FORMAT | 1/3.2″ |
| FOCAL LENGTH | 4.4mm |
| F.O.V.@5.7 | 65° |
| H.F.O.V. | 52° |
| RESOLUTION | 8 MP |
| DISTORTION | <-1% |
| APERTURE | F2.4 |
| MOUNT | M8x0.35 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 6.4mm |
| LENS COMPOMEMT | 5P+IR cut |
CCL132044MPF Low distortion wide angle 4.4mm 52° M8 mount lens for IMX179 HD 8MP rectilinear scanning
