Low distortion wide angle 85° M12 mount lens 1/4″ HD 5MP rectilinear scanning
CCL14017MPF Low distortion wide angle 85° M12 mount lens 1/4″ HD 5MP rectilinear scanning
| IMAGE FORMAT | 1/4″ |
| FOCAL LENGTH | 1.7 mm |
| F.O.V. | 100°(D) |
| 85°(H) | |
| 73°(V) | |
| RESOLUTION | 5 megapixel |
| DISTORTION | <1% |
| APERTURE | F2.4 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| B.F.L. | 4 mm |
| T.T.L. | 16.2mm |
| CONSTRUCTION | 4G2P+IRF |
CCL14017MPF Low distortion wide angle 85° M12 mount lens HD 5MP rectilinear scanning
