CCL14040MPFR
CCL14040MPFR
Low distortion wide angle 4mm 50° M12 mount lens 1/4″ with HD 5MP rectilinear scanning
CCL14040MPFR Low distortion wide angle 4mm 50° M12 mount lens 1/4″ with HD 5MP rectilinear scanning
| IMAGE FORMAT | 1/4″ |
| FOCAL LENGTH | 4.0mm |
| F.O.V. | 60°(D) |
| 49.5°(H) | |
| 38°(V) | |
| RESOLUTION | 5 MP |
| DISTORTION | <-0.4% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 21.98mm |
| DIMENSION | Φ14×18.7mm |
| LENS COMPOMEMT | 2G2P+IR cut |
CCL14040MPFR Low distortion wide angle 4mm 50° M12 mount lens with HD 5MP rectilinear scanning
