CCLA13023MPF
CCLA13023MPF is a 2.3mm IP67 M12 S-Mount Automotive lens. It is designed for 1/3″ sensors like OV7960, PC1089 and 1/3″ CCD. It is a wide angle HD board lens with short T.T.L. 13mm.
| IMAGE FORMAT | 1/3″ |
| FOCAL LENGTH | 2.3mm |
| F.O.V. | 160°(D) |
| 115°(H) | |
| 95°(V) | |
| RESOLUTION | Megapixel |
| TV DISTORTION | <18% |
| APERTURE | F2.5 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 3mm |
| M.O.D. | 0.15m |
| LENS COMPONEMT | 2G2P+IR cut |
| WATERPROOF | IP67 |
CCLA13023MPF 2.3mm automotive M12 S-mount board lens
