CCL23020MPF
CCL23020MPF
S-mount fisheye lens，large image circle Φ6.3mm and 190 degree for 10 MP sensors.
The S-mount fisheye lens CCL23020MPF with large image circle Φ6.3mm and 190 degree. And it is high resolution good for more than10 MP sensors.
| IMAGE FORMAT | Φ6.0mm |
| FOCAL LENGTH | 2.0mm |
| F.O.V.@Φ6.0 | 190° |
| F.O.V.@Φ4.6 | 140° |
| RESOLUTION | 10 MP |
| F-THETA DIS. | -4.9% |
| APERTURE | F2.5 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| B.F.L. | 4.35mm |
| CONSTRUCTION | 7G+IR cut |
Fisheye lens, M12 lens, S-Mount lens CCL23020MPF
