CCL13013MP

M12接口鱼眼镜头 Φ3.52mm的成像圈，1/3”传感器 IR校正的，360全景CCTV日夜两用监控。

描述

M12接口鱼眼镜头CCL13013MP具有Φ3.52mm的成像圈，适用于1/3英寸百万像素传感器。是有IR校正的，适应于360全景CCTV日夜两用监控。

IMAGE FORMAT	Φ3.52mm
FOCAL LENGTH	1.3mm
F.O.V.(1/3″)	180°(D)
	180°(H)
	180°(V)
RESOLUTION	3Megapixel
OPTICAL DISTORTION	<-100%
APERTURE	F2.0
MOUNT	M12x0.5
IRIS	Fixed
M.O.D.	0.2m
T.T.L.	23.89mm
M. B.F.L.	5.45mm
CONSTRUCTION	6G

Download Specs Sheet
